| Uniform Capacity Retracted (lbs.) |
2,500 |
| Uniform Capacity Battery Extended (lbs.) |
1300 |
| Uniform Capacity Manually Extended (lbs.) |
600 |
| Width Between Legs/Wheels – Retracted (in.) |
23 |
| Width Between Legs/Wheels – Extended (in.) |
28 |
| Manual Extension Holes (quantity) |
3 |
| Space Between Holes (in.) |
8 |
| Max. Height – Crane Extended (in.) |
110 |
| Max. Length – Legs Extended (in.) |
103-1/8 |
| Lift Range – Retracted (in.) |
46-7/8 |
| Lift Range – Extended (in.) |
122 |
| Drive Motor |
DC24V / 0.7KW |
| Lift Motor |
DC24V / 2KW |
| Battery (quantity) |
2 |
| Battery Type |
12V / 80-95AH |
| Battery Charger |
24V / 12 AMP |
| Battery Charger Power Cord |
115V AC |
| Minimum Service Per Charge (hrs.) |
8 |
| Lift Speed w/o Load (seconds) |
0.7 |
| Lift Speed w/ Load (seconds) |
0.5 |
| Lower down speed w/o load (seconds) |
0.25 |
| Lower down speed w/ Load (seconds) |
0.75 |
| Travel speed w/o load (mph) |
2.8 |
| Travel speed w/load (mph) |
2.18 |
| Drive Wheel Size Diameter/Width (in.) |
10 x 3.15 |
| Rear Caster (quantity) |
2 |
| Rear Caster Size Diameter/Width (in.) |
3 x 1.375 |
| Front/Leg Caster (quantity) |
2 |
| Front/Leg Caster Size (in.) |
6 x 2 |
| Wheel/Caster Material |
Poly-On-Steel |
| Lowered Height at 43.5 in Reach 2500 lbs (in.) |
22 |
| Raised Height at 43.5 in Reach 2500 lbs (in.) |
70 |
| Lowered Height at 70 in Reach 1300 lbs (ins.) |
12.5 |
| Raised Height at 70 in Reach 1300 lbs (in.) |
90 |
| Lowered Height at 94 in Reach 600 lbs (ins.) |
4 |
| Raised Height at 94 in Reach 600 lbs (ins.) |
110 |
